  • Exploded schematic of Segway AT6 SGW570F Section 18, callout 18 is the 12 "front rim glossy black
Segway AT6 SGW570F 14 "front Anti-stripping Rim - T08000029001

Segway AT6 SGW570F 14 "front Anti-stripping Rim - T08000029001

$14.00 $22.00
Details

Genuine Segway Powersports 14 "front Anti-stripping Rim, Part No. T08000029001

Fitment

  • Segway SGW570F-A1: Section 18, callout #13

Part details

  • Part type: Pin
  • Qty per assembly: 1

Assembly Diagram Reference

Numbers below match the callouts in the schematic image.

# Part Part Number Qty
1 Tire 25x8.00-12, CU01 (Cst) T08121000011 1
1 Tire 25x8.00-12, CP350 (Wanda) T08122000011 1
1 Tire 26x8.00-12, P3058 (Wanda) T08122000021 1
2 Tire 26x8.00-14, CU05P (Cst) T08121000031 1
2 Tire 26x8.00-14, P373 (Wanda) T08122000031 1
3 Nut, Hub Installation Piece (Black) T08000011002 4
4 Aluminum Rim Trim Cover T08000020001 1
5 Cotter Pin 5 X 50 GBT000091007 1
6 Hexagon Slotted Thin Nut M24 GBT009459003 1
7 A- Washer 24 GBT000971008 1
8 Valve T08100001001 1
9 Bolt M8x25 GBT005789096 16
10 Peak Green Anti Slip Ring T08000009001 1
10 Red Anti Slip Ring T08000009002 1
10 Blue Anti Slip Ring T08000009004 1
10 Black Anti Slip Ring T08000009007 1
11 Front Anti-dealuminization Wheel Rim A03F21010001 1
12 Anti-detachment Screw Sleeve T08000015001 16
13 14 "front Anti-stripping Rim (this part) T08000029001 1
14 14 " Front Aluminum Rim T08000027001 1
15 Nut, Hub Installation Piece (Black) T08000016002 4
16 Steel Rim Trim Cover T08000013001 1
18 12 "front Rim Glossy Black T08000001001 1
19 Rim Mount Assembly A03F20010001 1
20 Rim Installation Piece A03F20011001 1
21 Bolt, Rim (Black) T08000014002 4

Genuine Segway Powersports replacement part, supplied to OEM specification. Before ordering, confirm the part number against the exploded schematic image, which shows this part’s exact position (callout number) within its assembly. Where a compatibility note appears in the listing, it takes precedence. Order the quantity shown under “Qty per assembly” for a complete replacement; hardware and seals are sold individually unless stated otherwise. Unsure about fitment? Contact us with your model and VIN before purchase.
