  • Exploded schematic of Segway AT6 SGW570F Section 15, callout 16 is the screw m4x12
Segway AT6 SGW570F Fixed Plate - F01K00021001

Segway AT6 SGW570F Fixed Plate - F01K00021001

$14.00 $22.00
Details

Genuine Segway Powersports Fixed Plate, Part No. F01K00021001

Fitment

  • Segway SGW570F-A1: Section 15, callout #5

Part details

  • Part type: OEM replacement part
  • Qty per assembly: 1

Assembly Diagram Reference

Numbers below match the callouts in the schematic image.

# Part Part Number Qty
1 Crank Position Sensor (Cps) E01K00300001 1
2 O-Ring 17x2 F01K00301001 1
3 Bolt M6x16 F01000002001 3
4 Ignition Coil F01K00600001 1
5 Fixed Plate (this part) F01K00021001 1
6 Fuel Injector Adapter Press Plate F01K00002001 1
7 Fuel Injector Adapter F01K00001001 1
8 Fuel Injector F01K00400001 1
9 Bolt M6x20 F01000004001 1
10 Throttle Assembly E01K00500001 1
11 Tps, Map, Temperature Sensor E01K00510004 1
12 Stepper Motor E01K00510003 1
13 Throttle Cover Seal E01K00503001 1
14 Throttle Cable Stopper E01K00501001 1
15 Throttle Cover E01K00502001 1
16 Screw M4x12 GBT090744001 4

Genuine Segway Powersports replacement part, supplied to OEM specification. Before ordering, confirm the part number against the exploded schematic image, which shows this part’s exact position (callout number) within its assembly. Where a compatibility note appears in the listing, it takes precedence. Order the quantity shown under “Qty per assembly” for a complete replacement; hardware and seals are sold individually unless stated otherwise. Unsure about fitment? Contact us with your model and VIN before purchase.
