Segway AT6 SGW570FProtecting Bush
Sale price
$1.00
Regular price
$1.25
Taxes calculated at checkout
Diagram
Section 87
SGW570F-A1
Segway part number
A03F16506001
Callout
3
Per assembly
4
Pickup currently not available
-
Ships across Canada
Costs shown at checkout
-
Returns and refunds
See the policy -
Genuine Segway OEM
Matched by part number
Section 87 parts
15 parts. Numbers match the callouts on Segway's diagram; this part is callout 3.
| # | Part | Part Number | Qty |
|---|---|---|---|
| 1 | Screw M6x16 | GBT000701010 | 4 |
| 2 | Locking Cap Of Right Bracket | A03F16503001 | 2 |
| 3 | Protecting Bush (this part) | A03F16506001 | 4 |
| 4 | Screw M8x25 | GBT026731001 | 2 |
| 5 | Screw M6x20 | GBT000701011 | 4 |
| 6 | Right Bracket | A03F16502001 | 1 |
| 7 | Left Bracket | A03F16501001 | 1 |
| 8 | Right Shield | A03F16505001 | 1 |
| 9 | Left Shield | A03F16504001 | 1 |
| 10 | Connecting Base Of Left Bracket | A03F16508001 | 1 |
| 11 | Connector Of Right Bracket | A03F16510001 | 1 |
| 12 | Locking Base Of Right Bracket | A03F16509001 | 1 |
| 13 | Locking Base Of Left Bracket | A03F16507001 | 1 |
| 14 | Cross Recessed Hexagon Bolts M6x8 | GBT000818009 | 4 |
| 15 | Handguard Protector Assy | A02F16500001 | 1 |
Fits these Segway diagrams
- Snarler AT6 Section 87SGW570F-A13
Part details
- Part number
- A03F16506001
- Brand
- Segway Powersports
- Part type
- OEM replacement part
- Qty per assembly
- 4
Related parts

Not sure this is the right part?
Ask our parts team. Include your VIN and this part number.
