  • Exploded schematic of Segway AT6 SGW570F Section 29, callout 33 is the bolt m6x45
Segway AT6 SGW570F Rear Brake Pad - A02E11320001

Segway AT6 SGW570F Rear Brake Pad - A02E11320001

$14.00 $22.00
Details

Genuine Segway Powersports Rear Brake Pad, Part No. A02E11320001

Fitment

  • Segway SGW570F-A1: Section 29, callout #27

Part details

  • Part type: OEM replacement part
  • Qty per assembly: 2

Assembly Diagram Reference

Numbers below match the callouts in the schematic image.

# Part Part Number Qty
1 Three Brake Hydraulic Brake A02E11000001 1
2 FR Brake Assy A03E11200001 1
3 FR Caliper Brake A03E11210001 1
4 Front Brake Pad A03E11120001 2
5 Gasket A03E11012001 19
6 Bolt Inner Oil A03E11011001 8
7 FR Brake Oil Tube A03E11020001 1
8 Hydraulic Induction Switch A03E11005001 1
9 Fl Brake Oil Pipe A03E11010001 1
10 Fl Caliper Brake A03E11110001 1
11 Fl Brake Assy A03E11100001 1
12 Foot Brake Main Pump A03E11500001 1
13 Front Brake Oil Tube A03E11040001 1
14 Hydraulic Distribution Valve A03E11600001 1
15 Handbrake Oil Tube A03E11050001 1
16 All Metal Hexagonal Flange Lock Nut M6 GBT061871002 1
17 Brake Handle A03E11701001 1
18 Slotted Flat Head Step Screw M6x35 A03E11702001 1
19 Handbrake Pump A03E11700001 1
20 Brake Oil Cup A03E11800001 1
21 Clamp, Oil Cup Pipe A03E11803001 2
22 Oil Cup Pipe A A03E11801001 1
23 Oil Cup Pipe B A03E11802001 1
24 Foot Brake Main Pump Tube Clip A03E11804001 2
25 Rear Brake Oil Tube A02E11030001 1
26 Rear Caliper Brake A02E11310001 1
27 Rear Brake Pad (this part) A02E11320001 2
28 Rear Brake Assy A02E11300001 1
29 Hexagon Flange Bolt M6x12 GBT005789006 4
30 Hexagon Flange BOLTM10x1.25x25 GBT005789026 4
31 Bolt M8x25 GBT005789016 2
32 Hexagon Socket Head Screw M10x1.25x50 GBT000701007 2
33 Bolt M6x45 GBT005789063 2

Genuine Segway Powersports replacement part, supplied to OEM specification. Before ordering, confirm the part number against the exploded schematic image, which shows this part’s exact position (callout number) within its assembly. Where a compatibility note appears in the listing, it takes precedence. Order the quantity shown under “Qty per assembly” for a complete replacement; hardware and seals are sold individually unless stated otherwise. Unsure about fitment? Contact us with your model and VIN before purchase.
