  • Exploded schematic of Segway Fugleman UT10 Seat Bracket Assembly, callout 9 is the u01 seat rail front mounting bracket assembly
Segway Fugleman UT10 U01 Seat Rail Bracket Assembly - U01K11120001

Segway Fugleman UT10 U01 Seat Rail Bracket Assembly - U01K11120001

$14.00 $22.00
Details

Genuine Segway Powersports U01 Seat Rail Bracket Assembly, Part No. U01K11120001

Fitment

  • Segway UT10 (U1): Seat Bracket Assembly, callout #8

Part details

  • Part type: Bracket
  • Qty per assembly: 1

Assembly Diagram Reference

Numbers below match the callouts in the schematic image.

# Part Part Number Qty
1 U01 Seat Backrest Bracket Assembly U01K11110001 1
2 Nut M8 GBT061831003 4
3 Bolt M8x40 GBT005789019 4
4 U01 U-shaped Buffer Block Behind The Seat U01K11101001 2
5 Screw ST4.2x16 GBT000845010 2
6 U01 Seat Rail Rear Mounting Bracket Assembly U01K11140001 1
7 Screw M8x16 GBT000701014 4
8 U01 Seat Rail Bracket Assembly (this part) U01K11120001 1
9 U01 Seat Rail Front Mounting Bracket Assembly U01K11130001 1

Genuine Segway Powersports replacement part, supplied to OEM specification. Before ordering, confirm the part number against the exploded schematic image, which shows this part’s exact position (callout number) within its assembly. Where a compatibility note appears in the listing, it takes precedence. Order the quantity shown under “Qty per assembly” for a complete replacement; hardware and seals are sold individually unless stated otherwise. Unsure about fitment? Contact us with your model and VIN before purchase.
