  • Exploded schematic of Segway Villain SGW1000F Front Axle Assembly, callout 42 is the front axle assy
Segway Villain SGW1000F Front Axle Assy - Q03F00000002

Segway Villain SGW1000F Front Axle Assy - Q03F00000002

$14.00 $22.00
Details

Genuine Segway Powersports Front Axle Assy, Part No. Q03F00000002

Fitment

  • Segway SGW1000F-S1: Front Axle Assembly, callout #42
  • Segway SGW1000F-S1: Power Installation Assembly, callout #15
  • Segway SGW1000F-S2: Front Axle Assembly, callout #42
  • Segway SGW1000F-S2: Power Installation Assembly, callout #15
  • Segway UT10 (U1): Front Axle Assembly, callout #42
  • Segway UT10 (U1): Power Installation Assembly, callout #9

Part details

  • Part type: Assembly
  • Qty per assembly: 1

Assembly Diagram Reference

Numbers below match the callouts in the schematic image.

# Part Part Number Qty
1 Hexagon Flange Bolt M8x25 Q01F40201001 7
2 Oil Seal 38x55x7 D02P22202001 2
3 Breathing Joint Q01F41300001 1
4 Front Axle End Cover Q03F40200002 1
5 Rectangular Gasket Q01F40500001 1
6 Bearing 16010 GBT000276038 1
7 Limiting Liner Q01F40400001 1
8 Hexagon Flange Bolt M10x1.0x18 Q03F30800001 8
9 Differential Cover Q03F30200001 1
10 Axle Shaft Bevel Gear Gasket (0.8) Q01R31600001 1
10 Axle Shaft Bevel Gear Gasket (1) Q01R31600002 1
10 Axle Shaft Bevel Gear Gasket (1.2) Q01R31600003 1
11 Half Shaft Bevel Gear I Assembly Q03F30600000 1
12 Planetary Gear Shaft V Q03F30300001 1
13 Planetary Gear Liner Q01R31700003 2
14 Planetary Gear Q01R30900003 1
15 Half Shaft Bevel Gear Ii Q03F30700001 1
16 Differential Housing Q03F30100001 1
17 Drive Driven Bevel Gear Kit Q01F10100000 1
18 Axle Shaft Assy Q03F30900000 1
19 Combination Sets Q03F31000001 1
20 Spacer 40.2x50x3 Q03F31500001 1
21 Bushingi (Φ97) Q01F41000001 1
22 Bearing 16008 GBT000276015 1
23 Front Axle Housing Q03F40100002 1
24 Bushingii (Φ15) Q01F41100001 1
25 Drive Bevel Gear Shims (0.3) Q01F10200001 1
25 Drive Bevel Gear Shims (0.4) Q01F10200002 1
25 Drive Bevel Gear Shims (0.5) Q01F10200003 1
25 Drive Bevel Gear Shims (0.6) Q01F10200004 1
25 Drive Bevel Gear Shims (0.7) Q01F10200005 1
26 Bearing 3306 GBT000296001 1
27 Circlip 30 GBT000894012 1
28 Nut M75x1.5x6-LH Q01F41200001 1
29 Oil Seal 30x45x6.5 Q03F40700001 1
30 Bolt M6x16 F01000002001 4
31 Vehicle Speed Sensor Assembly Q01F50300001 1
32 O-Ring 12x2 Q01F40900001 1
33 Plug M14 F02C10008001 1
34 O-Ring 13.8x2.5 F01G00005001 2
35 Engine Drain Plug M14 F01G00200001 1
36 O-Ring 67.9x2.2 Q03F40300001 1
37 Front Axle Shift Motor Assembly Q03F50100001 1
38 Shift Fork Q03F31100001 1
39 Sliding Rack Q03F31200001 1
40 Fork Shaft 5x65 Q03F31300001 1
41 Hexagon Screw M8x8 Q03F31400001 1
42 Front Axle Assy (this part) Q03F00000002 1

Genuine Segway Powersports replacement part, supplied to OEM specification. Before ordering, confirm the part number against the exploded schematic image, which shows this part’s exact position (callout number) within its assembly. Where a compatibility note appears in the listing, it takes precedence. Order the quantity shown under “Qty per assembly” for a complete replacement; hardware and seals are sold individually unless stated otherwise. Unsure about fitment? Contact us with your model and VIN before purchase.
