  • Exploded schematic of Segway Villain SGW1000F Fuel System, callout 44 is the main fuel tank assembly
Segway Villain SGW1000F Fuel Filter Component - U01A52010001

Segway Villain SGW1000F Fuel Filter Component - U01A52010001

$14.00 $22.00
Details

Genuine Segway Powersports Fuel Filter Component, Part No. U01A52010001

Fitment

  • Segway SGW1000F-S1: Fuel System, callout #22
  • Segway SGW1000F-S2: Fuel System, callout #22
  • Segway UT10 (U1): Fuel Supply System-us Standard, callout #35
  • Segway SGW570F-A1: Section 58, callout #12

Part details

  • Part type: Filter
  • Qty per assembly: 2

Assembly Diagram Reference

Numbers below match the callouts in the schematic image.

# Part Part Number Qty
1 Fuel Tank Protection Pad S01A50106001 8
2 Fuel Tank Breather Pipe 1 S01-A507010-000-00 1
3 Clamp 20 QCT006211015 6
4 Main Fuel Tank S01-A511000-000-00 1
5 Oil Pump Assembly S03M43000001 1
6 Cap, Install Oil Pump U01A51500001 1
7 Aprons S03A50102001 4
8 T Type Bushing S01A50103001 6
9 Hexagon Flange Bolt M8x30 GBT005789017 6
10 Fuel Tank Block S01H20400001 4
11 Clamp 49 BQ006211-04912-001 2
12 Rubber Gasket For Fuel Tank S03A50106001 2
13 Fuel Filler Connection Hose S01-A501040-000-00 1
14 Fuel Filler S01-A513000-000-01 1
15 Bolt M8x25 GBT005789016 2
16 Oil Tank Cap (Unlock) S01A50105001 1
17 Positioning Tie Φ7x180 T05000001004 5
18 Fuel Tank Breather Pipe 2 S01-A507020-000-00 1
19 9.49 Quick Connect Plug (90 Degrees) T07000001004 1
20 Aingle Ear Clamp 16.5 T05000006001 12
21 High Pressure Fuel Pipe (Fuel Tank) S01-A505000-000-00 1
22 Fuel Filter Component (this part) U01A52010001 2
23 High Pressure Fuel Pipe (Engine) S01-A503000-000-00 1
24 7.89 Quick Connection Plug (0 Degree) T07000001001 1
25 Secondary Air Supplement Connection Tee U05A45006001 1
26 Fuel Tank Breather 3 S01-A507040-000-00 1
27 Negative Pressure Pump Oil Hose S01-A502000-000-00 1
28 Clamp, Springband 16 QCT006211005 1
29 Gravity Valve Breather Tube S01-A504000-000-00 1
30 Fuel Tank Connection Hose 2 S01-A507050-000-00 1
31 Single Ear Stepless Clamp 14.5 T05000003001 5
32 Single Ear Stepless Clamp 34.5 T05000009001 4
33 Fuel Tank Connection Hose S01-A507030-000-00 2
34 Negative Pressure Pump S03A50800001 1
35 Screws M6x20 GBT000702004 2
36 Connection Hose For Pressure Pump S03A50607001 1
37 Auxiliary Tank S01-A512000-000-00 1
38 Negative Pressure Pump Oil Inlet Hose 3 S01-A509000-000-00 1
39 Negative Pressure Pump Oil Inlet Hose 2 S01-A531002-000-02 1
40 Oil Inlet Connection Tee S03A51200001 1
41 Negative Pressure Pump Oil Inlet Hose 1 S01-A531001-000-01 1
42 CVT Outlet Pipe Drain Plug S05A20904001 1
43 Fuel Tank Suction Hose S01-A511011-000-00 1
44 Main Fuel Tank Assembly S01-A510000-000-00 1

Genuine Segway Powersports replacement part, supplied to OEM specification. Before ordering, confirm the part number against the exploded schematic image, which shows this part’s exact position (callout number) within its assembly. Where a compatibility note appears in the listing, it takes precedence. Order the quantity shown under “Qty per assembly” for a complete replacement; hardware and seals are sold individually unless stated otherwise. Unsure about fitment? Contact us with your model and VIN before purchase.
