Segway Villain SGW1000F Nut M10x1.25 - E02C00002001

Segway Villain SGW1000F Nut M10x1.25 - E02C00002001

$14.00 $22.00
Details

Genuine Segway Powersports Nut M10x1.25, Part No. E02C00002001

Fitment

  • Segway SGW1000F-S1: Upper And Lower Crankcase Sub-assembly, callout #22
  • Segway SGW1000F-S2: Upper And Lower Crankcase Sub-assembly, callout #22
  • Segway UT10 (U1): Upper And Lower Crankcase Sub-assembly, callout #22

Part details

  • Part type: Nut
  • Qty per assembly: 4

Assembly Diagram Reference

Numbers below match the callouts in the schematic image.

# Part Part Number Qty
1 Piston Injector Pressure Regulator F02C15000001 1
2 Piston Injector Assembly F02C16000001 1
2.1 Piston Cooling Nozzle E02-C160000-000-01 1
3 Bolt M6x35 F01000007001 11
4 Dowel Pin 6x10 GBT001192001 10
5 Bolt M8x40 F01000017001 2
6 Bolt M6x75 F02C11003001 1
7 Bolt M6x16 F01000002001 4
8 O-Ring 13.8x2.5 F01G00005001 4
9 Fuel Passage Assembly F02C13000001 1
10 Outlet Pipe F02C10010001 1
11 Plug M14 F02C10008001 1
12 Screw Plug M24 F02C10005001 1
13 O-Ring Seal 23x2.65 F02C10006001 1
14 Oil Filter Combination F02C12000001 1
15 O-Ring Seal 18x1.9 F02C10007001 1
16 Balance Shaft Bearing Compenent (Blue) F02C10003007 2
16 Balance Shaft Bearing Compenent (Red) F02C10003008 2
16 Balance Shaft Bearing Compenent (Black) E02-C100030-000-05 2
17 Crankcase Crankshaft Bushing (Blue) F02C10002006 4
17 Crankcase Crankshaft Bushing (White) F02C10002007 4
17 Crankcase Crankshaft Bushing (Red) F02C10002008 4
17.1 Upper Crankcase Crankshaft Bushing (Black) E02-C100010-000-05 4
17.2 Lower Crankcase Crankshaft Bushing (Black) E02-C100020-000-05 4
18 Oil Seal 47x70x12 F02C14000001 1
19 Bolt M10x1.25x110 F02C11010001 8
20 Bolt M8x90 F02C11004001 4
21 Oil Regulator Valve Unit E02-G003000-000-00 1
22 Nut M10x1.25 (this part) E02C00002001 4
23 Double-ended Stud M10x1.25x60 E02C00001001 4
24 Labyrinth Rubber Plug E02-C110006-000-01 1

Genuine Segway Powersports replacement part, supplied to OEM specification. Before ordering, confirm the part number against the exploded schematic image, which shows this part’s exact position (callout number) within its assembly. Where a compatibility note appears in the listing, it takes precedence. Order the quantity shown under “Qty per assembly” for a complete replacement; hardware and seals are sold individually unless stated otherwise. Unsure about fitment? Contact us with your model and VIN before purchase.
